| Ask Lasest Price | |
| Brand Name : | lenolink |
| Model Number : | LC-2S1 |
| Certification : | ISO |
| Price : | Negotiation |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 5000pcs/ month |
| Delivery Time : | 3-4 weeks |
Outdoor IP67 double band combiner with freqency 698-2700 with PIM 155dBc
1. Single and double units as optional
2. Easy to install
3. Outdoor IP67 waterproof
4. With Low PIM and low loss high performance combiner
| Type No. | |||
| Electrical | |||
| Port | Port1 | Port3 | |
| Frequency (MHz) | 1710-1880 | 2300-2700 | |
| Insertion Loss (dB) | ≤ 0.35 | ≤ 0.3 | |
| Isolation (dB) | ≥ 50 | ||
| VSWR | ≤ 1.25:1 | ||
| Impedance | 50 Ω | ||
| Input Power (c.w./per port) | ≤ 300 Watts | ||
| Intermodulation | ≤ -155dBc (3rd order; with 2×20W) | ||
| Environmental | |||
| Temperature Range | -20 to +55°C (Operating) | ||
| Humidity | 95% max, non condensing | ||
| Application | IP65 | ||
| Mechanical | |||
| Connectors | 7/16 DIN(F) | ||
| Colors | Grey, RAL 7035 (powdering) | ||
| Weight | ≤ 3 kg | ||
| Dimensions (w/o connectors) | 215*180*50 mm | ||
FAQ:
1. Q: How to control product quality?
A: All goods are tested, and the test report is provided. We have
strict QC before shipment and we provide a 2 years warranty.
2. Q: Can you send us samples to check? Samples for free?
A: We can ship you samples and send you pictures of product
details. However you need to pay for the sample fee.
3. Q: What is the MOQ?
A: 10 piece.
4. Q: What about payment terms?
A: L/C, D/A, D/P or T/T and others
If you have any other questions, please feel free to contact us.
|
|
